0.75 HP Threaded Shaft Full-Rated Two-Compartment Pool Pump Motor
- Black three phase threaded shaft pool pump motor
- Includes sealed ball bearings; reversible clockwise rotation
- Can withstand ambient temperature up to 50 degree Celsius
- Comes with stainless steel shaft for corrosion protection
- 11 inches high by 9.5 inches wide by 21 inches long
Description
Grab this affordable motor with 65 frames that delivers the performance you demand with the flexibility they desire. It helps you in maintaining the proper pool environment. The durability will save you money in the long run.
Product Features:
Includes sealed ball bearings and threaded shaft
Withstand ambient temperature up to 50°C
303 stainless steel shaft for corrosion protection
Additional Features:
Output HP: 0.75 Hp
Output KW: 0.56 kW
Frequency: 60 Hz
Voltage: 208-230/460 V
Current: SF 3.8-3.6/1.8 A
Speed: 3450 rpm
Service factor: 1.65
Phase: 3
Duty: continuous
Insulation class: B
Frame: Y56Y
Enclosure: drip proof
Thermal protection: thermally protected
Electrical type: poly phase, induction type, single or dual voltage
Poles: 2
Rotation: reversible clockwise
Mounting: square flange
Motor orientation: horizontal
Drive end bearing: ball
Shaft type: threaded
Dimensions: 11"H x 9.5"W x 21"L
Shaft diameter: 0.625"
Shaft extension: 0.91"
Frame length: 8.38"
Material(s): stainless steel
Frame: rolled steel
Product Specifications
| Weight | Width | Height | Depth |
|---|---|---|---|
| 25.00 LBS | 9.50" | 11.00" | 21.00" |
